Rockford Fosgate – M600-5

M600-5

The M600-5 is a 600 watt marine grade “all-in-one” amplifier featuring four full-range stereo channels and a dedicated mono subwoofer channel.

• Class A/B technology (4 channel)
• Class-D technology (sub channel)
• Remote Punch Level Control (sub channel) included
• RCA and high level input with 2/4/5 channel select
• 12 dB/Oct Butterworth crossovers
• On board Punch EQ control
• Separate Front, Rear and Sub gain control
• Real time output and power supply thermal sensing
• Cast aluminum heat sink
• 4 AWG power/ground connectors
• MOSFET power supply
• Over current and short circuit protection
• Marine grade two part epoxy coating on circuit boards
• Muted turn on
• 2 Year Standard Warranty

• CEA-2006 Compliant: CEA-2006 Guidelines CEA-2006 Power Rating 50Wx4 + 200Wx1 @ 4Ω ≤1.0% THD+N
• Number of Channels: 5
• Rated Power (RMS Continuous Power):50W x 4 + 200W x 1 @ 4-Ohm 75W x 4 + 300W x 1 @ 2-Ohm 150W x 2 @ 4-Ohm Bridged
• Total Power (Sum of Rated Power): 600 Watts RMS
• Dynamic Power (PVC/PowerCube®): 57W x 4 + 221W x 1 @ 4-Ohm 90W x 4 + 390W x 1 @ 2-Ohm 178W x 2 @ 4-Ohm Bridged
• Bridgeable: Yes (front/rear channels)
• Frequency Response: 20Hz to 20kHz +/-1dB
• Efficiency (average): Channels 1/2/3/4: 64% @ 4-Ohm
• Sub Channel: 85% @ 4-Ohm
• Crossover Controls: Front Channels: HP/LP Variable 50Hz – 250Hz @ 12dB/octave
• Rear Channels: HP/LP Variable 50Hz – 250Hz @ 12dB/octave
• Sub Channel: LP Variable 50Hz – 250Hz @ 12dB/octave
• Tone Controls: Front: 0/6/12dB @ 45Hz
• Rear: 0/6/12dB @ 45Hz
• Sub: Variable 0dB to 12dB @ 45Hz
• Signal Input: Low Level: 3 RCA Pair
• Signal Output: –
• Power Input Connector: Block
• Power Wire Gauge: 4 AWG
• Speaker Output Connector: Block
• Speaker Wire Gauge: 12 AWG
• Heat Sink Type: Cast Aluminum
• Cooling: Convection
• Remote Controls: Punch Level Control: When connected is linked to „gain control“ to provide remote output level
• Visual Indicators: Power Protect
• Circuit Topology Class: Front: Class-A/B
• Sub: Class-D
• Shipping Weight: 9.1 Lbs. (4.12 Kg.)
• Dimensions (H x W x D): 1.98″ x 6.77″ x 13.99″ (5cm x 17.2cm x 33.5cm)
