Soundstream – DTR1.1700D

Tired of the same ol‘ thing? Like to be different? So do we! Check out the D-Tower amplifiers for something truly revolutionary. When you don’t have a lot of floor space to give up, Go Vertical! The DTR1.2200D yields over 2000 watts of power in only 52 square inches. By comparison, our Tarantula TRX2000D takes up 250.8 square inches. You can fit almost FIVE DTR1.2200D amplifiers in the same area. Available in models from 900 to 3400 watts, the Class D’s can be complimented with the DTR4.500 full range 4-channel amplifier. All amplifiers have all of the controls facing rearwards and all of the wiring facing backward, making installation easy and clean. And for those of you who change your mind a lot, the amplifiers come with an extra set of feet to mount the amplifiers horizontally as well…

FEATURES

• The worlds first vertical automotive stereo amplifier
• Gloss black finish w/ brushed accents
• Double sided pcb w/ smd components
• Aluminum alloy heat-sink
• Regulated mosfet pwm power supply
• Three-way protection circuitry (thermal, short, impedance)
• Delayed on/off circuit
• Variable crossovers (hpf/full/lpf)
• Variable bass boost
• Variable subsonic filter
• Variable phase control
• High level input
• Dash mounted remote gain control
• Direct wire 4 ga. Power, 8 ga. Speaker terminals
• Horiziontal mounting feet included

• Channels :1 ch. Class D
• RMS Power @ 4Ω, 14.4V:
• RMS Power @ 2Ω, 14.4V: 1,100
• RMS Power @ 1Ω, 14.4V: 1,700
• RMS Power @ .5Ω, 14.4V:
• Total Harmonic Distortion (4 Ohm power): 0.50%
• Frequency Response: 10-220Hz
• Signal-to-Noise Ratio (4 Ohm power): 91dB
• Damping Factor (100Hz, 4Ohm): >200
• Signal Voltage: 200mV-5V
• Recommended Fusing: 150A
• Dimensions: 19,05 cm x 8,57 cm x 37,15 cm
• Channels 1&2 HPF (12dB/octave):
• Channels 1&2 LPF (18dB/octave): 40-220Hz
• Channels 3&4 HPF (12dB/octave):
• Channels 3&4 LPF (18dB/octave):
• Bass Boost: 0-12dB, 30-90Hz
• Subsonic Filter: 12dB, 10-50Hz
• Phase Control: 0-180°
• Remote Gain Control: Included
